BMT65 Boring Bar & Indexable Drill Block, Ø 40 mm, 72 mm Centre Height

Name: BMT65 Boring Bar & Indexable Drill Block, Ø 40 mm, 72 mm Centre Height
Brand: EASYCUT
SKU: 128-21802
Price: 260.59 EUR
Availability: InStock

128-2180211 unit in stock

Bolt-on block for BMT65 turrets: Ø 40 H7 bore for round-shank boring bars and indexable drills, 72 mm centre height, two externally routed coolant channels. Three screws clamp from the side, two more from the top stop an indexable drill from twisting in the bore. For Doosan Puma, HAAS ST and DS, Hyundai WIA, Hwacheon, Maxsin, SMEC, Tongtai and Victor with BMT65.

€260.59 incl. taxes

€379.55

Retail price as of 11.03.2026

11 unitab Lager Berlin (BE)

Product Attributes

Technical Description

Reviews

Turret Type

BMT65

Toolholder Type

Boring Bars, Indexable Drills

Bore Diameter, mm

Centre Height, mm

Brand

EASYCUT

Item type

Drehmaschine Werkzeughalter

Turret Type:BMT65

Bolt pattern and standard dimensions, mm

bmt65 standard dims.jpeg

Technical Description

BMT65 boring bar and indexable drill block 128-21802 - dimensioned drawing with Ø 40 H7 bore, 72 mm centre height, 117 x 95 mm footprint

Bolt-on block for lathes with a BMT65 turret. The Ø 40 H7 bore takes round-shank boring bars and indexable drills; smaller shank diameters go in with reducer sleeves.

Turret interface	BMT65
Bore	Ø 40 H7
Centre height	72 ±0.02 mm
Overall height	105 mm
Footprint	117 × 95 mm
Clamping	3 side + 2 top
Coolant	2 channels, external
Weight	6.6 kg

Two screws from the top. Three M10×25 screws clamp the shank from the side — enough for a boring bar. An indexable drill cutting into solid material produces high torque that wants to twist the drill body in the bore. Against that, the top face of the block carries two short M10×12 screws that press on the clamping flat of the drill shank. On the drawing they sit in the top view, on the centreline. Without those two screws it is version 128-21801, otherwise identical.

Mounting. Four screws onto the turret disc, aligned by a key. What decides the fit is the BMT65 hole pattern on your own turret — the machine list below is a guide.

Spare parts. Side clamping screw 811-102039 (M10×25) · top clamping screw 811-102036 (M10×12) · key 814-203310 · screw for key 811-101027.

Machines. Doosan Puma, HAAS ST and DS, Hyundai WIA, Hwacheon, SMEC, Tongtai and Victor with a BMT65 turret.
